What exactly do cloud providers charge us for?#

There are a million ways to pay cloud providers money, and trying to understand it all is several books worth of material.

However, a lot of JupyterHub (+ optionally Dask) clusters operate in similar ways, so we can focus on a smaller subset of ways in which cloud companies charge us.

This document is designed not to be comprehensive, but to provide a baseline understanding of things in the cloud that cost money so we can have a baseline to reason from.

Nodes / Virtual Machines#

The unit of compute in the cloud is a virtual machine (a node in kubernetes terminology). It is assembled from the following components:

  1. CPU (count and architecture)

  2. Memory (only capacity)

  3. Boot disk (size and type, ephemeral)

  4. Optional accelerators (like GPUs, TPUs, network accelerators, etc)

Let’s go through each of these components, and then talk about how they get combined.

CPU#

CPU specification for a node is three components:

  1. Architecture (x86_64 / amd64 or arm64 or aarch64)

  2. Make (Intel vs AMD vs cloud provide made ARM processor, what year the CPU was released, etc)

  3. Count (total number of processors in the node)

The ‘default’ everyone assumes is x86_64 for architecture, and some sort of recent intel processor for make. So if someone says ‘I want 4 CPUs’, we can currently assume they mean they want 4 x86_64 Intel CPUs. x86_64 intel CPUs are also often the most expensive - AMD CPUs are cheaper, ARM CPUs are cheaper still. So it’s a possible place to make cost differences - but, some software may not work correctly on different CPUs. While ARM support has gotten a lot better recently, it’s still not on par with x86_64 support, particularly in scientific software - see this issue for an example. AMD CPUs, being x86_64, are easier to switch to for cost savings, but may still cause issues - see this blog post for how the specifics of what CPU are being used may affect some software. So these cost savings are possible, but require work and testing.

Count thus becomes the most common determiner of how much the CPU component of a node costs for our usage pattern.

Memory#

Unlike CPU, memory is simpler - capacity is what matters. A GB of memory is a GB of memory! We pay for how much memory capacity the VM we request has, regardless of whether we use it or not.

Boot disk (ephemeral)#

Each node needs some disk space that lives only as long as the node is up, to store:

  1. The basic underlying operating system that runs the node itself (Ubuntu, COS or similar)

  2. Storage for any docker images that need to be pulled and used on the node

  3. Temporary storage for any changes made to the running containers in a pod. For example, if a user runs pip install or conda install in a user server, that will install additional packages into the container temporarily. This will use up space in the node’s disk as long as the container is running.

  4. Temporary storage for logs

  5. Any emptyDir volumes in use on the node. These volumes are deleted when the pod using them dies, so are temporary. But while they are in use, there needs to be ‘some place’ for this directory to live, and it is on the node’s ephemeral disk

  6. For ephemeral hubs, their home directories are also stored using the same mechanism as (3) - so they take up space on the ephemeral disk as well. Most hubs have a persistent home directory set up, detailed in the Home directories section.

These disks can be fairly small - 100GB at the largest, but we can get away with far smaller disks most of the time. The performance of these disks primarily matters during initial docker image pull time - faster the disk, faster it is to pull large docker images. But it can be really expensive to make the base disks super fast SSDs, so often a balanced middling performance tier is more appropriate.

Accelerators (GPU, etc)#

Accelerators are a form of co-processor - dedicated hardware that is more limited in functionality than a general purpose CPU, but much, much faster. GPU are the most common ones in use today, but there are also TPUs, FGPAs available in the cloud. Accelerators can often only be attached to a subset of a cloud provider’s available node types, node sizes, and cloud zones.

GPUs are the most commonly used with JupyterHubs, and are often the most expensive as well! Leaving a GPU running for days accidentally is the second easiest way to get a huge AWS bill (you’ll meet NAT / network egress, the primary culprit, later in this document). So they are usually segregated out into their own node pool that is exclusively for use by servers that need GPUs - a kubernetes taint is used to exclude all other user servers from those nodes. The cluster autoscaler can stop the GPU node as soon as there are are actual GPU users, thus saving cost.

Combining resource sizes when making a node#

While you can often make ‘custom’ node sizes, most commonly you pick one from a predefined list offered by the cloud provider (GCP, AWS, Azure). These machine types are primarily pre-defined sets of CPU (of a particular generation, architecture and count), RAM and optionally an accelerator (like GPU).

For the kinds of workloads we have, usually we pick something with a high memory to CPU ratio, as notebooks (and dask workers) tend to be mostly memory bound, not CPU bound.

Autoscaling makes nodes temporary#

Nodes in our workloads are temporary - they come and go with user needs, and get replaced when version upgrades happen. They have names like gke-jup-test-default-pool-47300cca-wk01 - notice the random string of characters towards the end. The cluster autoscaler is the primary reason for a new node to come into existence or disappear, along with occasional manual node version upgrades.

Since nodes are often the biggest cloud cost for communities, and the cluster autoscaler is the biggest determiner of how / when nodes are used, understanding its behavior is very important in understanding cloud costs.

Documentation: GCP, AWS, Azure

Home directory#

By default, we provide users with a persistent, POSIX compatible filesystem mounted under $HOME. This persists across user server restarts, and is used to store code (and sometimes data).

Because this has to persist regardless of whether the user is currently active or not, cloud providers will charge us for it regardless of whether the user is actively using it or not. Hence, choosing what cloud products we use here becomes crucial - if we pick something that is a poor fit, storage costs can easily dwarf everything else.

The default from z2jh is to use Dynamic Volume Provisioning, which sets up a separate, dedicated block storage device (think of it like a hard drive) ((EBS on AWS, Persistent Disk on GCP and Disk Storage on Azure)) per user. This has the following advantages:

  1. Since there is one drive per user, a user filling up their disk will only affect them - there will be no effect on other users. This removes a failure mode associated with one shared drive for all users - a single user can use up so much disk space that no other users’ server can start!

  2. Performance is pretty fast, since the disks are dedicated to a single user.

  3. It’s incredibly easy to set up, as kubernetes takes care of everything for us.

However, it has some massive disadvantages:

  1. The variance in how much users use their persistent directory is huge. Our observation is that most users use only a little bit of storage, and a few users use a lot of storage. By allocating the same amount of disk space to each user, a lot of it is wasted, unused space. But, we pay for all this unused space! Sometimes this means we’re paying for about 90% of disk space that’s unused!

That single cost related disadvantage is big enough that we do not use the default home directory set up at all! Instead, we use some sort of shared storage - a single storage device is provisioned for all the users on a hub, and then subdirectories are mounted via NFS. This is more complicated and offers lower performance, but the cost model of a pooled disk is so much cheaper that it is worth it.

In the past, we have done this by managing an NFS server manually. While cheaper on some cloud providers, it requires specialized knowledge and maintenance. Instead, we use the following products on various cloud providers:

  1. Elastic Filesystem (EFS) on AWS

    There is no upper limit on size, and we are charged only for what we use. Most ideal shared storage product.

  2. Google Filestore on GCP

    We have to specify a maximum storage capacity, which can never be reduced, only increased. We pay for the maximum storage capacity, regardless of what we use.

    The smallest filestore we can provision is 1TiB, which is overkill for many of our communities. But it’s the best we can do on GCP.

  3. Azure Files on Azure

    We have to specify a maximum storage capacity, which can be adjusted up or down. We pay for the maximum storage capacity, regardless of what we use.

Network Fees#

Back in the old days, ‘networking’ implied literally running physical cables between multiple computers, having an RJ45 criping tool in your pocket, and being able to put physical tags on cables so you could keep track of where the other end of the cable was plugged into. Changing network configuration often meant literally unplugging the configuration in which physical wires were plugged from one device into another, manually logging into specific network devices and changing configuration.

When doing things ‘in the cloud’, while all these physical tasks still need to be performed, we the users of the cloud are not privy to any of that. Instead, we operate in the world of software defined networking (or SDN). The fundamental idea here is that instead of having to phsycially connect cables around, you can define network configuration in software somehow, and it ‘just works’. Without SDN, instead of simply creating two VMs in the same network from a web UI and expecting them to communicate with each other, you would have to email support, and someone will have to go physically plug in a cable from somewhere to somewhere else. Instead of being annoyed that ‘new VM creation’ takes ‘as long as 10 minutes’, you would be happy that it only took 2 weeks.

Software Defined Networking is one of the core methodologies that make the cloud as we know it possible.

Almost every interaction in the cloud involves transmitting data over the network. Depending on the source and destination of this transmission, we may get charged for it, so it’s important to have a good mental model of how network costs work when thinking about cloud costs.

While the overall topic of network costs in the cloud is complex, if we are only concerned with operating JupyterHubs, we can get away with a simplified model.

Network Boundaries#

There are two primary aspects that determine how much a network transmission costs:

  1. The total amount of data transmitted

  2. The network boundaries it crosses

(1) is fairly intuitive - the more data that is transmitted, the more it costs. Usually, this is measured in ‘GiB of data transmitted’, rather than smaller units.

(2) is determined by the network boundaries a data packet has to cross from source to destination. Network boundaries can be categorized in a million ways. But given we primarily want to model network costs, we can consider a boundary to be crossed when:

  1. The source and destination are in different zones of the same region of the cloud provider

  2. The source and destination are in different regions of the same cloud provider

  3. Either the source or destination is outside the cloud provider

If the source and destination are within the same zone, no network cost boundaries are crossed and usually this costs no money. As a general rule, when each boundary gets crossed, the cost of the data transmission goes up. Within a cloud provider, transmission between regions is often priced based on the distance between them - australia to the US is more expensive than Canada to the US. Data transmission from within a cloud provider to outside is the most expensive, and is also often metered by geographical location.

This also applies to data present in any cloud services as well, although sometimes in those cases transmission is free even in a different zone in the same region. For example, with AWS S3 data transfer (under the ‘Data Transfer’ tab), accessing S3 buckets in the same region is free regardless of what zone you are in. But, with GCP Filestore, you do pay network fees if you are mounting it from a different zone even if it is in the same region. So as a baseline, we should assume that any traffic crossing network zone boundaries will be charged, unless explicitly told otherwise.

Primarily, this means we should design and place services as close to each other as possible to reduce cost.

Ingress and Egress fees#

Cloud providers in general don’t want you to leave them, and tend to enforce this lock-in by charging an extremely high network egress cost. Like, ‘bankrupt your customer because they tried to move a bucket of data from one cloud provider to another’ high egress cost. Cloudflare estimates that in US data centers, it’s about 80x what it actually costs the big cloud providers. The fundamental anti-competitive nature how egress fees can hold your data ‘hostage’ in a cloud provider is finally causing regulators to crack down, but only under limited circumstances ( AWS, GCP).

So when people are ‘scared’ of cloud costs, it’s most often network egress costs. It’s very easy to make a bucket public, have a single other person try to access it from another cloud provider, and get charged a lot of money.

While scary, it’s also fairly easy for us to watch out for. A core use of JupyterHub is to put the compute near where the data is, so most likely we are simply not going to see any significant egress fees at all, as we are accessing data in the same region / zone. Object storage access is the primary point of contention here for the kind of infrastructure we manage, so as long as we are careful about that we should be ok. If you have data in more than one region / zone, set up a hub in each region / zone you have data in - move the compute to where the data is, rather than the other way around.

More information about managing this is present in the object storage section of this guide.

Object storage#

Object Storage is one of the most important paradigm shifts of the ‘cloud’ revolution. Instead of data being accessed as files via POSIX system calls (like read, write, etc), data is stored as objects and accessed via HTTP methods over the network (like GET, PUT, etc). This allows for much cheaper storage, and much higher scalability at the cost of a little more complexity (as all data access becomes a network call). While home directories may store users’ code, the data is either currently already being stored in object storage, or is going to be stored that way in the near future.

While object storage has been around since the 90s, it was heavily popularized by the introduction of AWS S3 in 2006. A lot of modern object storage systems are thus described as ‘S3 compatible’, meaning that any code that can access data from S3 can also access data from these systems automatically.

Storage fees, operation fees and class#

When storing data in object storage, you have to select a storage class first. This determines both the latency of your data access as well as cost, along with some additional constraints (like minimum storage duration) for some classes. While this can be set on a per object basis, usually it is set at the bucket level instead.

Once you have picked your storage class, the cost associated is down to the amount of data stored and the number of operations performed on these objects. Amount of data stored is simple - you pay a $ amount per GB of data stored per month.

There’s a cost associated with each operation (GET, PUT, LIST, etc) performed against them. Mutating and listing operations usually cost an order of magnitude more than simple read operations. But overall the fees are not that high - on AWS, it’s $0.0004 for every 1,000 read requests and $0.005 for every 1,000 write requests. Given the patterns in which most JupyterHubs operate, this is not a big source of fees.

The cheaper it is to store, the more expensive it is to access. The following table of costs from S3 illustrates this - and this is not all the classes available!

Class

Storage Fee

Access Fee

Standard

$0.023 / GB

$0.0004 / 1,000 req

Standard - Infrequent Access

$0.0125 / GB

$0.001 / 1,000 req

Glacier Deep Archive

$0.00099 / GB

$(0.0004 + 0.10) / 1,000 req + $0.02 per GB

Picking the right storage class based on usage pattern is hence important to optimizing cost. This is generally true for most cloud providers. A full guide to picking storage class is out of scope for this document though.

Pricing link: AWS S3, GCP GCS, Azure Blob Storage

Egress fees#

As discussed in the network fees section, egress fees are how cloud providers often lock you in. They want you to store all your data in them, particularly in their object stores, and charge an inordinate amount of money to take that data with you somewhere else. This is egregious enough now that regulators are noticing, and that is probably the long term solution.

In the meantime, the answer is fairly simple - never expose your object store buckets to the public internet! Treat them as ‘internal’ storage only. JupyterHubs should be put in the same region as the object store buckets they need to access, so this access can be free of cost, even avoiding the cross-region charges.

If you must expose object store data to the public internet, consider getting an OSN Pod (NSF funded). They provide fully compatible object stores with zero egress fees and fairly good performance. And perhaps, if you live in a rich enough country, let your regulator know this is an anti-competitive practice that needs to end.

LoadBalancers#

Each cluster uses a single kubernetes service of type LoadBalancer to get any HTTP(S) traffic into the cluster. This creates a single “Load Balancer” in the cloud provider, providing us with a static IP (GCP & Azure) or CNAME (AWS) to direct our traffic into.

After traffic gets into the cluster, it is routed to various places via kubernetes ingress objects, backed by the community maintained ingress-nginx provider (not the VC backed nginx-ingress provider). So users access JupyterHub, Grafana, as well as any other service through this single endpoint.

Each Load Balancer costs money as long as it exists, and there is a per GB processing charge as well. Since we don’t really have a lot of data coming in to the JupyterHub (as only user sessions are exposed via the browser), the per GB charge usually doesn’t add up to much (even uploading 1 terabyte of data, which will be very slow, will only cost between $5 - $14).

  1. AWS ELB

    We currently use Classic Load Balancers as that is the kubernetes default. Pricing varies by region, but is mostly $0.025 per hour + $0.008 per GB.

  2. GCP Cloud LoadBalancing

    Pricing varies by region, but is about $0.0327 per hour per load balancer (listed as ‘forwarding rule’ in the pricing page, as our load balancers only have one forwarding rule each)

    • $0.01046 per GB processed.

  3. Azure LoadBalancer

    Pricing varies by region, but is about $0.025 per hour per load balancer (listed as a ‘rule’ in the pricing page, as our load balancers only have one rule each) + $0.005 per GB processed.

Access to the external internet#

Users on JupyterHubs generally expect to be able to access the external internet, rather than only internal services. This requires one of two solutions:

  1. Each node of our kubernetes cluster gets an external IP, so each node has direct access to the external internet.

  2. A single Network Address Translation (NAT) device is set up for the cluster, and all external traffic goes through this.

There are cost (and sometimes quota) considerations for either option.

Public IP per node#

If each node gets a public IP, any traffic to the external internet looks like it is coming from the node. This has two cost considerations:

  1. There is no charge for any data coming in on any of the cloud providers, as it is counted purely as ‘data ingress’. So if a user is downloading terabytes of data from the public internet, it’s almost completely free. Sending data out still costs money (as metered by ‘data egress’), but since our usage pattern is more likely to download massive data than upload it, data egress doesn’t amount to much in this context.

  2. On some cloud providers, there is a public IP fee that adds to the cost of each node. This used to be free, but started costing money only recently (starting in about 2023).

    Cloud Provider

    Pricing

    Link

    GCP

    $0.005 / hr for regular instances, $0.003 / hr for pre-emptible instances

    link

    AWS

    $0.005 / hr

    link (see ‘Public IPv4 Addresses’ tab)

    Azure

    $0.004 / hr

    link (Dynamic IPv4 Address for “Basic (ARM)”

This is the default mode of operation for our clusters, and it mostly works ok! We pay for each node, but do not have to worry about users racking up big bills because they downloaded a couple terabytes of data. Since the originating IP of each network request is the node the user pod is on, this also helps with external services (such as on-prem NASA data repositories) that throttle requests based on originating IP - all users on a hub are less likely to be penalized due to one user exhausting this quota.

There are two possible negatives when using this:

  1. Each of our nodes is directly exposed to the public internet, which means theoretically our attack surface is larger. However, these are all cloud managed kubernetes nodes without any real ports open to the public, so not a particularly large risk factor.

  2. Some clouds have a separate quota system for public IPs (GCP, Azure), so this may limit the total size of our kubernetes cluster even if we have other quotas.

Cloud NAT#

The alternative to having one public IP per node is to use a Network Address Translation (NAT) service. All external traffic from all nodes will go out via this single NAT service, which usually provides a single (or a pool of) IP addresses that this traffic looks to originate from. Our kubernetes nodes are not exposed to the public internet at all, which theoretically adds another layer of security as well.

Dr. Who Meme about Cloud NAT. One of the many memes about Cloud NAT being expensive, from [QuinnyPig](https://twitter.com/QuinnyPig/status/1357391731902341120). Many seem far more violent. See [this post](https://www.lastweekinaws.com/blog/the-aws-managed-nat-gateway-is-unpleasant-and-not-recommended/) for more information.

However, using a cloud NAT for outbound internet access is the single most expensive thing one can do on any cloud provider, and must be avoided at all costs. Instead of data ingress being free, it becomes pretty incredibly expensive.

Cloud Provider

Cost

Pricing Link

GCP

$(0.044 + 005) per hour + $0.045 per GiB

link

AWS

$0.045 per hour + $0.045 per GiB

link

Azure

$0.045 per hour + $0.045 per GiB

link

Data ingress costs go from zero to $0.045 per GiB. So a user could download a terabyte of data, and it costs about $46 instead of $0. This can escalate real quick, because this cost is invisible to the user.

The shared IP also causes issues with external services that throttle per IP.

So in general we should completely avoid using NATs, unless forced to by external constraints - primarily, some organizations might force a ‘no public IPs on nodes’ policy. While this may be useful policy in cases where individual users are creating individual VMs to do random things, it is counterproductive in our set up - and only makes things expensive.

Other Persistent Disk Storage#

We use dedicated, always on block storage for the following parts of the infrastructure:

  1. The hub database

    This stores the sqlite3 database that the JupyterHub process itself uses for storing user information, server information, etc. Since some of our hubs rely on admins explicitly adding users to the hub database via the hub admin, this disk is important to preserve.

    It is usually 1GiB in size, since that is the smallest disk we can get from many of these cloud providers. However, on Azure, we also store the hub logs on this disk for now - so the disk size is much larger.

    High performance is not a consideration here, so we usually try to use the cheapest (hence slowest disk) possible.

  2. Prometheus disk

    We use prometheus to store time series data, both for operational (debugging) as well as reporting (usage metrics) purposes. We retain 1 year of data, and that requires some disk space. We try to not use the slowest disk type, but this doesn’t require the fastest one either.

    Currently, most prometheus disks are bigger than they need to be. We can slim them down with effort if needed.

  3. Grafana disk

    Grafana also uses a sqlite database the same way JupyterHub does. While most of the dashboards we use are managed in an external repo, the database still holds user information as well as manually set up dashboards. This does not need to be fast, and we also try to have the smallest possible disk here (1GiB)

  4. Optional per-user disk for dedicated databases

    One of the features we offer is a database per user, set up as a sidecar. Most databases do not want to use NFS as the backing disk for storing their data, and need a dedicated block storage device. One is created for each user (via Kubernetes Dynamic Volume Provisioning), and this can get quite expensive (for reasons outlined in the “Home Directory Storage” section).

Pricing is primarily dependent on the expected disk performance (measured as throughput and IOPS) as well as the disk size. While there’s a lot of options available, we’ll list what we most commonly use in this table.

Cloud Provider

Cost

Pricing Page

GCP

Standard (Slow) - $0.048 / GB / month, Balanced (Most common) - $0.12 / GB / month

link

AWS

gp2 (most common) - $0.1 / GB / month

link

Azure

???

link

Kubernetes Cluster management#

Cloud providers charge for maintaining the Kubernetes cluster itself, separate from the nodes used to run various things in it. This is usually a fixed per hour cost per cluster.

  1. AWS EKS

    Costs $0.10 per hour flat.

  2. GCP GKE

    Costs $0.10 per hour flat.

    There is a discount of about 75$ per month allowing one zonal (single zone, non highly available) cluster per GCP billing account continuously for free. This discount is of little value to us and communities since since we favor the regional (multi-zone, highly available) clusters for less disruptive kubernetes control plane upgrades, and since we don’t manage that many separate billing accounts.

    GKE also has an ‘autopilot’ edition that we have tried to use in the past and decided against using, for various restrictions it has on what kind of workloads it can run.

  3. Azure AKS

    Our clusters are currently on the Free tier, so don’t cost any money. Their documentation suggests this is not recommended for clusters with more than 10 nodes, but we’ve generally not had any problems with it so far.

Image Registry#

We primarily have people use quay.io to store their docker images, so usually it doesn’t cost anything. However, when we have dynamic image building enabled, we use the native container image registry in the cloud provider we use. Usually they charge for storage based on size, and we will have to eventually develop methods to clean unused images out of the registry. Exposing built images publicly will subject us to big network egress fees, so we usually do not make the built images available anywhere outside of the region / zone in which they are built.

Pricing links: GCP, AWS, Azure

Logs#

Logs are incredibly helpful when debugging issues, as they tell us exactly what happened and when. The problem usually is that there’s a lot of logs, and they need to be stored & indexed in a way that is helpful for a human. All the cloud providers offer some (possibly expensive) way to store and index logs, although whether it is actually helpful for a human is up for debate. The following resources produce logs constantly:

  1. The Kubernetes control plane itself (all API requests, node joinings, etc)

  2. The various system processes running on each node (kernel ring buffer, container runtime, mount errors / logs, systemd logs, etc)

  3. Kubernetes components on each node (kubelet, various container runtimes, etc)

  4. All kubernetes pods (we access these with kubectl logs while they are active, but the logging system is required to store them for use after the pod has been deleted)

  5. Kubernetes Events

  6. The Cluster Autoscaler (to help us understand autoscaling decisions)

  7. Probably more. If you think ‘this thing should have some logs’, it probably does, if you can find it.

Google cloud has StackDriver, which is automatically already pre-configured to collect logs from all our clusters. AWS supports CloudWatch for logs, but they aren’t enabled by default. Azure probably has at least one product for logs.
